ADSS all-dielectric self-supporting optical cable is a non-metallic optical cable that is composed entirely of dielectric materials，contains the necessary support system，and can be directly hung on power poles and towers. It is mainly used for communication lines of overhead high-voltage transmission systems，and can also be used Communication lines in overhead laying environments such as lightning-prone areas and long-span environments.
Operating temperature：-40℃～65℃
Characteristic：All Dielectric
Cable Type：Stranded Loose tube ADSS Cable
Jacket Material：Polyethylene (PE) | AT(anti-tracking)Sheath
Fiber Count：12-144Core
Subunit Type：Gel-filled
Environmental Space：Self-supporting Aerial
Armor：Aramid Yarn| KEVLAR
Standards：Comply with standard IEC 60794-4、IEC 60793、TIA/EIA 598 A.
Product structure：PBT loose tube，non-metallic central reinforcement (FRP)，PE inner sheath，aramid fiber layer，PE outer sheath or anti-tracking outer sheath
Applications：Self-support Aerial Installation，Used for communication lines in overhead high-voltage transmission systems，lightning-prone areas，large-span and other overhead laying environments.
Fiber Type: G652D；G655C；G657A1；G657A2；50/125；62.5/125；OM3-150；OM3-300；OM4 As Options
1、In new and old power lines，they should be erected on the same tower as the power lines；
2、Occasions that require large leaps；
3、Areas with strong electric fields、frequent lightning and cold etc.
Standard length：2000m, other lengths are also available
